Blacklights |

UV-400

These super-powerful and versatile lamps have been specially engineered for fluorescent penetrant and magnetic particle inspection, parts degreasing inspections and wash station inspections.

Powerful, 400-watt metal halide bulb, combined with tempered, heat-resistant low solarization UV filters provide the highest intensity over the largest area
Easily mounts over automated magnetic particle systems or above penetrant inspection booths for the most accurate inspections of even the largest parts
Unique twin-filter system eliminates hazardous UV-B and UV-C radiation escaping from lamp
Compact design and built-in mounting features allow lamps to be positioned anywhere – even in previously inaccessible areas

TRI-450B

The Perfect NDT Lamp When UV-A Emissions Are a Concern!

Feature three cool-running, ultra-high flux 450 nm blue light LEDs with a broad-beam configuration. This powerful lamp provides a wider coverage area than conventional inspection lamps, while its compact head design allows access into areas inaccessible to larger inspection lamps. Ideal for most non-destructive testing applications.

Nominal steady-state intensity of 9,500 μW/cm2 at 15 inches (38 cm)
Large 5 inch (13 cm) diameter coverage area at 15 inches (38 cm), with a minimum intensity of 2,000 μW/cm2
100,000-hour LED service life
Rubber bumper with patented thin-film dichroic lens filters out long-wave visible light
Electronic Intensity Stabilizer ensures consistent LED performance
Built-in fans keep LEDs cool to maintain optimum light output during extended use
Instant-on operation. Lamp reaches full intensity immediately!
Rugged, ergonomic, angled lamp body provides safe, fatigue-free handling
Choice of standard 8 foot (2.4 m) or extra-long 20 foot (6.1 m) heavy-duty power cord with AC plug and rubber boot. Also available: Optional in-line power supply or industrial power supply with cord sets (sold seperately). All power supplies in 120V, 230V, 240V or 100V models.
Includes yellow contrasting spectacles and soft carrying case

OPK-300N

A New Powerful, Versatile, Multiple Wavelength, NDT Inspection Light!

The OPK-300N Multi-Lite® Kit features three Qwik-Connect™ interchangeable LED lamp heads that connect to a rugged, black-anodized flashlight body. It provides specific illumination in UV-A and blue light, and is ideal for both pre-screening of fluorescent particles in ambient light conditions and full- fledged NDT inspections utilizing magnetic particles or fluorescent penetrants. A convenient white light LED provides general illumination of dark work areas.

Super-powerful LED optical output with ultra-highintensity 365 nm UV-A and 450 nm blue light performance
Provides nominal steady-state intensity of 18,000 µW/cm2 (UV LED) or 7,000 µW/cm2 (blue light LED) at 15 inches (38 cm)
Blue light LED with patented thin-film dichroic lens filters out long-wave visible light
Electronic Intensity Stabilizer ensures consistent performance. Beam strength will not weaken between charges!
Instant-on operation. Lamp reaches full intensity immediately!
Lightweight, cordless, ergonomic design eliminates fatigue
Meets ASTM UV-A intensity specifications for FPI and MPI
Powered by a rechargeable NiMH battery. Provides 90 minutes of continuous inspection between charges (smart AC and DC chargers included). AC charger available in 120V, 230V, 240V and 100V versions.

Labino UVG series headlamp

Small, light and powerful, UVG torch is a convenient tool for quick inspections. UVG headlight is compact, light and adjustable that frees your hands during inspections.

UVG Series products UVG2-5 are small and compact lights with a powerful output that offer convenience during quick inspections.

UVG2 and UVG3 torches weigh just 211 grams (7.4 oz) and the UVG4 and UVG5 headlights weigh just 271 grams (9.4 oz). The UVG3 torch and UVG5 headlight have been specifically designed to meet the ASTM E3022-15 and ISO 3059-12 standards as well as requirements set by the PRIMES.

Spectro-UV Vintage 365 Handheld LED UV-A Inspection Lamp for NDT

Classic Design. Modern Technology. Economic Price.

VINTAGE ERGONOMIC DESIGN
Classic design with modern LED technology

COST EFFECTIVE
Quality lamp at economic price

WIDE BEAM PROFILE
Light output equivalent to classic HID lamps

FANLESS DESIGN
Cool running and efficient

Key Features and Benefits

Nominal steady state intensity of 5,500 µW/cm2 at 15 inches
Less than 1 fc of visible light emission
Wide beam diameter of 8 in (21 cm) of at least 1,200 µW/cm2 at 15 inches
Meets ISO 3059 specifications
Certificate of Light Output included
Lightweight – 2.1 lbs (0.95 kg)
Long-lasting UV-A lenses
Ergonomic handle, durable housing
Cool running, fanless design
Consistent beam profile
Reliable performance

Spectro-UV uVision 365 Series UV Light

For use in any Nondestructive Evaluation or Specialty Application that requires UV-A light.

Lightweight, IP 65 Rated inspection lamps can be used in nondestructive evaluation, forensics, and security inspections. In addition to three powerful UV-A LEDs, the uVision comes with a convenient White LED for illuminating work areas.

Key Features and Benefits

Cordless – portable for use in the field
Battery in the handle – self-contained unit
Long battery life: 8-12 hours
Quick charging: 3-4 hours
Large battery base – can stand up on its own
D-ring hook on backplate – for storage or belt clip
IP65 rating – dust-proof and water-resistant
Cool-running, fan-less design
Wide, even beam profile
Long-lasting UV-A lenses protect against solarization
Adjustable white light
Meets ISO EN 3059 specs for fluorescent inspection
ASTM E3022 Compliant Versions Available
RRES 90061 Compliant Versions Available
AITM6-1001 Compliant Versions Available
