Illuminators |

FL-5000-US-SG Single Arm LED Fiber Optic Illuminator

Designed for microscopy and general illumination, this unit is energy efficient and features cool white LED lighting with a color temp of 5000K and higher output than the typical 150 watt halogen fiber optic illuminator. The FL-5000 supports and fully illuminates gooseneck and annular ring light fiber optics. It is also a great option for inspection equipment, forensics, machine vision, industrial borescopes, assembly stations, and OEM custom lighting. The long life LED’s of this unit are rated to provide over 40,000 hours of light.

Product Information:
• Warranty: 2 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 9 lbs (4.0kg)
• Box Size: 15 x 15 x 9 inches

Technical Information
Light Output:	2000+ Lumens (12.7mm aperture)
Lighting:	High Power White LEDs
Input Voltage:	100 – 240 VAC 50/60 Hz
Color Temperature:	Typical: 5000 K
LED Life:	40,000 Hours D70
Fiber Optic Interface:	15 mm or (25 mm optional)
Operating Temperature:	5 – 40°C
Cooling:	Fan Cooled
Intensity Control:	Variable 10 – 100%
Dimension/Weight:	7.0” (W) X 4.9” (H) X 8.8” (D) (6 lbs)
Appovals:	ETL, CE, RoHS

FL-6000-US-B1 Power Supply LED

The FL-6000 is energy efficient and features bright white LED lighting with a color temperature of 6000K, and higher output than the typical 150-Watt halogen fiber optic illuminator. This unit supports and fully illuminates gooseneck and annular ring light fiber optics.

The FL-6000 does not have lamps or fuses that could fail, or lamp sockets that could wear out. The long life LED’s of this unit provides more than 25,000 hours of light.

Our high intensity, energy efficient LED fiber optic illuminators deliver bright white LED lighting and higher output than 150 watt halogen light sources. Designed for microscopy applications, the FL-6000 supports dual arm, single arm, and annular light guide configurations.

15 mm (.590″) Fiber Input Diameter. Includes 115V US line cord.

Product Information:
• Manufactured: 100% MADE IN USA
• Warranty: 1 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 9 lbs (4.0kg)
• Box Size: 15 x 15 x 9 inches

Technical Information
Light Output:	780 Lumens
Lighting:	High Power White LEDs
Input Voltage:	100 – 240 VAC 50/60 Hz
Color Temperature:	Typical: 6000 K
LED Life:	25,000 Hours D65
Fiber Optic Interface:	15 mm or (25 mm optional)
Operating Temperature:	0 – 40°C
Cooling:	Fan Cooled
Intensity Control:	15 Step
Dimension/Weight:	3.9” (W) X 5.1” (H) X 7.0” (D) (6.5 lbs)
Appovals:	CE, RoHS

FL-6000-US-DG Dual Arm LED Fiber Optic Illuminator

The FL-6000 is energy efficient and features bright white LED lighting with a color temperature of 6000K, and higher output than the typical 150-Watt halogen fiber optic illuminator. This unit supports and fully illuminates gooseneck and annular ring light fiber optics.

The FL-6000 does not have lamps or fuses that could fail, or lamp sockets that could wear out. The long life LED’s of this unit provides more than 25,000 hours of light.

Our high intensity, energy efficient LED fiber optic illuminators deliver bright white LED lighting and higher output than 150 watt halogen light sources. Designed for microscopy applications, the FL-6000 supports dual arm, single arm, and annular light guide configurations.

Includes Dual Gooseneck, Focusing Lens, & 115V US line cord.

Product Information:
• Manufactured: 100% MADE IN USA
• Warranty: 1 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 9 lbs (4.0kg)
• Box Size: 15 x 15 x 9 inches

Technical Information
Light Output:	780 Lumens
Lighting:	High Power White LEDs
Input Voltage:	100 – 240 VAC 50/60 Hz
Color Temperature:	Typical: 6000 K
LED Life:	25,000 Hours D65
Fiber Optic Interface:	15 mm or (25 mm optional)
Operating Temperature:	0 – 40°C
Cooling:	Fan Cooled
Intensity Control:	15 Step
Dimension/Weight:	3.9” (W) X 5.1” (H) X 7.0” (D) (6.5 lbs)
Appovals:	CE, RoHS

FL-6000-US-RL Annular LED Fiber Optic Illuminator

The FL-6000 is energy efficient and features bright white LED lighting with a color temperature of 6000K, and higher output than the typical 150-Watt halogen fiber optic illuminator. This unit supports and fully illuminates gooseneck and annular ring light fiber optics.

The FL-6000 does not have lamps or fuses that could fail, or lamp sockets that could wear out. The long life LED’s of this unit provides more than 25,000 hours of light.

Our high intensity, energy efficient LED fiber optic illuminators deliver bright white LED lighting and higher output than 150 watt halogen light sources. Designed for microscopy applications, the FL-6000 supports dual arm, single arm, and annular light guide configurations.

Includes 60 mm ID Ringlight. Includes 115V US line cord.

Product Information:
• Manufactured: 100% MADE IN USA
• Warranty: 1 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 9 lbs (4.0kg)
• Box Size: 15 x 15 x 9 inches

Technical Information
Light Output:	780 Lumens
Lighting:	High Power White LEDs
Input Voltage:	100 – 240 VAC 50/60 Hz
Color Temperature:	Typical: 6000 K
LED Life:	25,000 Hours D65
Fiber Optic Interface:	15 mm or (25 mm optional)
Operating Temperature:	0 – 40°C
Cooling:	Fan Cooled
Intensity Control:	15 Step
Dimension/Weight:	3.9” (W) X 5.1” (H) X 7.0” (D) (6.5 lbs)
Appovals:	CE, RoHS

FL-6000-US-SG Single Arm LED Fiber Optic Illuminator

The FL-6000 is energy efficient and features bright white LED lighting with a color temperature of 6000K, and higher output than the typical 150-Watt halogen fiber optic illuminator. This unit supports and fully illuminates gooseneck and annular ring light fiber optics.

The FL-6000 does not have lamps or fuses that could fail, or lamp sockets that could wear out. The long life LED’s of this unit provides more than 25,000 hours of light.

Our high intensity, energy efficient LED fiber optic illuminators deliver bright white LED lighting and higher output than 150 watt halogen light sources. Designed for microscopy applications, the FL-6000 supports dual arm, single arm, and annular light guide configurations.

Includes Single Gooseneck, Focusing Lens, & 115V US line cord.

Product Information:
• Manufactured: 100% MADE IN USA
• Warranty: 1 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 9 lbs (4.0kg)
• Box Size: 15 x 15 x 9 inches

Technical Information
Light Output:	780 Lumens
Lighting:	High Power White LEDs
Input Voltage:	100 – 240 VAC 50/60 Hz
Color Temperature:	Typical: 6000 K
LED Life:	25,000 Hours D65
Fiber Optic Interface:	15 mm or (25 mm optional)
Operating Temperature:	0 – 40°C
Cooling:	Fan Cooled
Intensity Control:	15 Step
Dimension/Weight:	3.9” (W) X 5.1” (H) X 7.0” (D) (6.5 lbs)
Appovals:	CE, RoHS

FR-LED LED Ring Illuminator

The FR-LED is our newest ring illuminator. It features the newest surface mount LED technology that is paired with our exclusive design criteria, to make the highest performance, longest operating, lowest cost LED ring illuminator sold today! The days of having to buy replacement bulbs are a thing of the past!

Our ESD Safe FR-LED features instant-on performance, with zero flicker. It is fully dimmable, from 100-0% with an integrated switch on the shade. Our exclusive design also allows for all circuitry to be hidden inside the shade. All other competitors rely on desktop controller boxes for their dimming units… another FR-LED advantage!

Our exclusive heat management system ensures supreme light output, for many years to come. The special thermal transfer system quickly and efficiently cools the LED array, for the longest life span in the industry. We are the only manufacturer to invest such extensive time and money into the development of the world’s best LED ring illuminator.

The FR-LED features an auto switchable 100-240v power supply, and boasts worldwide regulatory approvals. What this means is that this one unit, can be sold anywhere across the world with nothing more than a cord change for the destination country of choice.

Unlike many of the low end imported and domestic competition, our FR-LED array is the only one that can be replaced in the field, as well as can have individual LED chips be repaired, further reducing operating costs over the life span. Many other designs are simply one time use ‘throw away’ builds. We stand behind the FR-LED with our iron clad 5 Year / 50,000 Hour Warranty.

Product Information:
• Inner Diameter: 22.4mm
• Manufactured: 100% MADE IN USA
• Warranty: 5 Year Warranty
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight: 2.25lbs
• Box Size: 9 x 8 x 4 inches

MA305/100 (115V) Fluorescent Ring Light

The MA305 fluorescent illuminator provides cool, white diffused illumination similar to to daylight, and is suitable for low magnification examination for surface details of delicate organisms that sensitive to heat, or for specimens with such surface reflection. It provides 360° of cool white shadow-free illumination. Lightweight, compact, rugged.

Product Information:
• Light Output: 8W
• Color Tempature: 6500K
• Lamp Life: 1500 Hours
• Manufactured: 100% MADE IN JAPAN
• Warranty: LIMITED LIFETIME WARRANTY
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight:
• Box Size:

MA305/200 (220/240V) Fluorescent Ring Light

The MA305 fluorescent illuminator provides cool, white diffused illumination similar to to daylight, and is suitable for low magnification examination for surface details of delicate organisms that sensitive to heat, or for specimens with such surface reflection. It provides 360° of cool white shadow-free illumination. Lightweight, compact, rugged.

Product Information:
• Light Output: 8W
• Color Tempature: 6500K
• Lamp Life: 1500 Hours
• Manufactured: 100% MADE IN JAPAN
• Warranty: LIMITED LIFETIME WARRANTY
• Customer Support: 1-(800) 832-0060 (U.S.A Based)

Package Information:
• Weight:
• Box Size:
